MMBR Processing Device

The MMBR treatment device is suitable for the treatment of municipal sewage, village sewage, various industrial organic wastewater, and medical wastewater, especially for high standard discharge, reclaimed water reuse, land scarcity, emergency mobility, and unmanned scenarios.

National Service Hotline：400-611-6861
Product Introduction

The MMBR treatment device integrates MBBR mobile bed biofilm and MBR membrane separation technology, integrating efficient biochemistry and precise solid-liquid separation. It can efficiently degrade pollutants such as COD, ammonia nitrogen, and total nitrogen, and has excellent effluent quality, which can be directly discharged or reused in compliance with standards. The device has strong resistance to water quality impact load, low residual sludge production, and small footprint. It can be made into an integrated modular structure, which is fast to install and stable to operate. The system has a high degree of automation and can achieve unmanned operation and maintenance. It is widely used in various sewage treatment and upgrading projects such as municipal, rural, hospital, food, chemical, and aquaculture.

Technical Advantage
Efficient composite process
By integrating MBBR and MBR technologies, the biological concentration is high, and the removal efficiency of COD, ammonia nitrogen, and total nitrogen is outstanding. The effluent can stably meet the standard or be reused.
Small impact resistance and footprint
Resistant to fluctuations in water quality and quantity, low sludge production rate, no need for large structures, high integration, and significant land saving.
Stable and intelligent operation
The membrane separation effect is reliable, the system operates automatically, the management is simple, the remaining sludge is minimal, and the operation and maintenance costs are low.
Strong adaptability and flexibility
Modular and modular design, quick installation, suitable for new construction, upgrading and renovation, and temporary emergency sewage treatment scenarios.
Process Selection

1. MMBR standard process

MBBR biochemical+membrane separation combination is suitable for routine organic wastewater in municipal, rural, hospital and other areas, with stable and compliant effluent.

2. Strengthen denitrification and phosphorus removal processes

Pre anoxic/anaerobic+MMBR, aimed at upgrading and transforming sewage plants with high requirements for total nitrogen and total nitrogen, as well as treating black and odorous water bodies.

3. Pre treatment+MMBR process

Coagulation sedimentation/air flotation/filtration+MMBR, suitable for industrial wastewater containing oil, high suspended solids, and high chromaticity (food, slaughter, printing and dyeing).

4. MMBR+deep treatment process

MMBR+activated carbon/disinfection/RO, meeting the requirements of reclaimed water reuse, zero discharge, and high standard surface water quality.

5. Pry and install emergency technology

Integrated MMBR is suitable for mobile and quick installation scenarios such as temporary construction sites, field mining areas, and disaster relief emergencies.

Equipment Selection

1. Core biochemical system

Biological filler: Efficient suspended MBBR filler, with a large specific surface area, fast film formation, and impact resistance

Membrane module: PVDF hollow fiber membrane, high flux, pollution resistance, easy to clean

2. Selection of main structure

Material: Carbon steel anti-corrosion/304 stainless steel/fiberglass

Form: Integrated buried/pry mounted/modular combination

3. Aeration and hydraulic system

Aeration equipment: Micro porous aeration disc/high-efficiency cyclone aeration

Reflux system: sludge reflux pump, mixed liquid reflux pump

4. Self control and auxiliary systems

Control: PLC fully automatic control, online monitoring of water quality, automatic water production, backwashing, and sludge discharge

Supporting facilities: grille, regulating tank, dosing device, disinfection equipment, membrane cleaning system

5. Scene adaptation selection

Underground type: residential areas, hospitals, scenic spots, small footprint, good noise reduction

Explosion proof and anti-corrosion type: special working conditions such as chemical industry, oil field, mining area, etc

Mobile: Vehicle mounted/Skid mounted, with flexible transfer capability
