Smart modular medical wastewater treatment system

core technology

The intelligent modular medical wastewater treatment equipment adopts "pretreatment+A2O+precipitation+disinfection", which efficiently degrades organic matter, suspended solids, ammonia nitrogen, etc. in medical wastewater by controlling the MLSS concentration, DO concentration, reflux ratio and other process technical parameters in the biochemical system. The effluent is disinfected to kill bacteria, pathogens, etc.

System Composition

① Pre disinfection unit (optional for infectious disease hospitals)

② Biological processing unit

③ Efficient sedimentation unit

④ Physical and chemical disinfection unit

⑤ Dechlorination unit (optional)

⑥ Equipment operation unit

The effluent meets the relevant requirements of the "Discharge Standards for Water Pollutants in Medical Institutions" (GB18466-2005).

Medical wastewater pre disinfection and purification system

The pre disinfection and purification system integrates coagulation, precipitation, filtration, and disinfection combination technologies, adopts the principle of dissolution disinfection, innovates the design of automatic slow-release pressure chlorination disinfection process, and optimizes the structural design to ensure that the disinfectant fully contacts with water for sterilization and disinfection. The treated effluent meets the pre-treatment standard requirements of the "Discharge Standards for Water Pollutants in Medical Institutions" (GB18466-2005).

Craftsmanship and Characteristics

1. Stable effluent meets the standard;

2. Fully enclosed structure design to prevent pathogen transmission and leakage;

3. Underwater unpowered equipment to prevent cross infection between sewage and people during maintenance;

4. Intelligent automation control, realizing human-machine dialogue, remote platform supervision and operation, unmanned operation;

5. Intelligent detection of residual chlorine to ensure the effectiveness of effluent treatment;

6. Modular design, can be installed underground, above ground or semi underground, making it convenient for project implementation.

1. The effluent is stable and meets the standard, with high resistance to impact loads, fully meeting the requirements for wastewater treatment in medical institutions;

2. The main body is made of weather resistant steel and special anti-corrosion technology, with a lifespan of over 20 years;

3. Fully enclosed structure design, equipped with exhaust gas collection, deodorization and disinfection devices to prevent pathogen transmission and leakage;

4. Underwater unpowered equipment to prevent cross infection between sewage and people during maintenance;

5. Low operating costs, with an electricity consumption of about 0.2 kWh/ton of sewage;

6. The control distribution system adopts imported components, which are safe, stable and reliable;

7. Intelligent operation and maintenance big data platform, achieving unmanned operation;

8. Modular design facilitates flexible combination of engineering projects and facilitates construction and management; 9. It can be installed underground, above ground, or semi underground for the convenience of project implementation.
